Sunny Mini Central 6000A

Sunny Boy 3000TL

The Sunny Mini Central 6000A can be easily used for different type of connections universally. It is installed at all places where galvanic isolation is required and it can be used with crystalline cells as well as thin-film modules. The Sunny Mini Central SMC6000A has passed proven performance testing, thus offering the highest degree of flexibility in plant design. It is ideal for three phase systems and comes integrated with ESS DC switch-disconnector for better safety.

  • OptiCool active temperature management
  • OptiTrac MPP tracking for best tracking efficiency
  • SUNCLIX DC connection system
  • It is suitable for grounding the generator
Input (DC)
Max. DC power (@ cos ϕ =1)6300 W
Max. DC voltage600 V
MPP voltage range246 V - 480 V
DC nominal voltage270 V
Min. DC voltage / start voltage211 V / 300 V
Max. input current / per string26 A / 26 A
Number of MPP trackers / strings per MPP tracker4/1
Output (AC)
AC nominal power (@ 230 V, 50 Hz)6000 W
Max. AC apparent power6000 VA
Nominal AC voltage; range220, 230, 240 V;
180 V - 260 V (262 V**)
AC grid frequency; range50, 60 Hz; ± 4.5 Hz
Max. output current26 A
Power factor (cos ϕ )1
Phase conductors / connection phases / power balancing1 / 1 /●
Efficiency
Max. efficiency / Euro-eta96.1 % / 95.3 %
General data
Dimensions (W / H / D) in mm468 / 613 / 242
Weight63 kg
Operating temperature range–25 °C ... +60 °C
Noise emission (typical)≤ 42 dB(A)
Internal consumption (night)0.25 W
TopologyLF transformer
Cooling conceptOptiCool
Electronics protection rating / connection area (as per IEC 60529)IP65 / IP65
Climatic category (per IEC 60721-3-4)4K4H
  • RS485 interface of type 485PB-NR
  • SMA Power Balancer Plug connector PBL-SMC- 10-NR
  • Bluetooth® Piggy Back
  • Grounding set Positive ESHV-P-NR
  • Grounding set Negative ESHV-P-NR
